MAN eTGX 20.450 LLS-U EB WB375 330kW — electric 4×2 tractor. Tractor, 4×2, electric drive, power 450 hp, maximum fifth wheel weight 9960 kg.
The electric tractor from MAN. With 330 kW / 449 hp power, in this version with seven battery packs, good for 540 kWh, range estimated at 500 km. The tare weight in this version is 10,540 kg, resulting in a limited fifth wheel load of only 9960 kg despite the nine-ton front axle. For your reassurance: there will also be a 6×2, which we will introduce to you soon.
Charging is possible as standard with 375 kW, optionally with 500 kW on the right or 1 MW (megawatt) on the left.
Here are the technical data.
technical specifications *)
MAN eTGX 20.450 LLS-U EB WB375 330kW — electric 4×2 tractor
model year 2025 –
engine type MAN eCD330
emission class Z
max. power 330 kW
automatic transmission available as standard TipMatic
drive rear axle
number of tyres 6
axle configuration 4×2
wheelbase 375 cm
tarra 10540 kg
gvw 20500 kg
max. axle load front 9000 kg
max. axle load rear 11500 kg
range 500 km
max. fifth wheel load 9950 kg
capacity drive battery 480 or 540 kWh
max. charging capacity 375 (optional: 500 and/or 1000) kW
max. train weight 50000 kg
length 629 cm
width 255 cm
height 400 cm
fifth wheel height approx. 110 cm
cabin type sleeper cabin
cabin length 228 cm
*) subject to change. Exact specifications can be requested from the supplier.
