Kässbohrer K.SSK 60 — Kässbohrer’s lightest tipper silo trailer. Tipper silo trailer, maximum payload 32.75 tons, volume 60,000 liters.
With an unladen weight of only 6,250 kg, the K.SSK 60 is the lightest 60 m³ tipper silo trailer on the market. The optimized discharge geometry and smooth aluminum surfaces ensure a continuous and smooth material flow.
An electrolytically polished stainless steel discharge cone and four stainless steel distributors are standard equipment for improved efficiency and low maintenance. All valves, couplings, and ventilation systems in the discharge cone are easily removable for easy cleaning, increased safety, and faster operation, resulting in lower costs.
Equipped with a five-stage hydraulic tipping system with a lifting capacity of 150 bar for operational efficiency.
Gross vehicle weight: 39,000 kg
Fifth-wheel load: 12,000 kg
Axle load: 3 x 9,000 = 27,000 kg
Tare weight: 6,250 kg +/- 3%
Payload: +/- 32,750 kg
Coupling height: 122 cm
Wheelbase: 748 cm
Length: 1,306 cm
Tank diameter: 253 cm
Operating temperature: -20 – +80 degrees Celsius
Operating pressure: 2.0 bar
Technical specifications *)
Tare weight approx. 6,250 kg
Payload capacity approx. 32,750 kg
Max. fifth wheel pressure 12,000 kg
Max. rear axle load 27,000 kg
Load volume 60,000 dm³
Exhibitor: Kässbohrer Sales GmbH
*) Subject to change. Exact specifications can be requested from the supplier.
