Krone SZ — DA05CLNF — Insulated short semi-trailer with steering axle. Insulated trailer, 11.5 meters long, steered rear axle, load capacity 21,500 kg.
Insulated city semi-trailer with a length of 11.5 meters. Without refrigeration unit. Used for the distribution of drugstore products. Two nine-ton axles, the rear axle is steered. The front axle is a lifting axle. Equipped with a hydraulic Dhollandia tail lift and hinged rear doors. Maximum kingpin load is 12 tons. Equipped with bicycle guards, rear bumper, and LED lighting. Wheelbase: 770 cm. Distance from the center of the kingpin to the rear of the trailer: 970 cm.
Technical specifications *)
Krone SZ — DA05CLNF — Insulated short semi-trailer with steering axle
Length 1154 cm
Width 260 cm
Height 400 cm
Internal length / loading length 1140 cm
Internal width / loading width 248 cm
Gross vehicle weight 30,000 kg
Tare weight 8,500 kg
Payload 21,500 kg
Max. fifth wheel pressure 12,000 kg
Max. axle load 18,000 kg
Load volume approx. 73,800 dm³
*) Subject to change. Exact specifications are available from the supplier.
