MAN — Wierda — TGS 42.480 8×2-6 WideSpread — asphalt tipper chassis. Chassis for asphalt tipper, 8×2, widespread, 480 hp.
MAN TGS chassis, modified to widespread for use as an asphalt tipper by Wierda Voertuigtechniek from Joure. The third axle is the driven axle. Axles 1, 2, and 4 are steered. Due to the widespread arrangement of the two rear axles, the legally permitted load is 21,500 kg instead of 19,000 kg.
With a length of just over 8 meters, this is an extremely maneuverable chassis. Equipped with the reliable 12.4-liter six-cylinder engine, in this version with 480 hp / 353 kW. Suitable for all brands of tipper bodies. The tare weight of this chassis is approximately 9,300 kg.
Technical specifications *)
MAN — Wierda — TGS 42.480 8×2-6 WideSpread — Asphalt tipper chassis
Engine type: 6-cylinder common rail diesel
Displacement: 12419 cc
Emission class: Euro 6
Max. power: 353 kW
Revs at max. power: 1600 rpm
Max. torque: approx. 2200 Nm
Revs at max. torque: 1400 rpm
Number of gears: 16
Automatic transmission available: standard automatic transmission
Drive axle: 3
Number of tires: 10
Axle configuration: 8×2-6
Wheelbase: 582.5 cm
Tare weight without body: 9300 kg
gvw: 41500 kg
Max. axle load front: 20000 kg
Max. axle load rear: 21500 kg
Gross payload: 32200 kg
Length: 805 cm
Width: 255 cm
Number of seats 2
Cab type: Day cab
*) Subject to change. Exact specifications can be requested from the supplier.
