Iveco eDaily 38S14E/P Chassis. Van chassis, electric drive, for B or BE driving licence.
Iveco eDaily electric chassis, with a gross vehicle weight (gvw) of 3.8 tonnes. Electric motor under the cab, battery attached to the chassis, rear-wheel drive. Two batteries with a total energy storage capacity of 148 kWh (of which 140 kWh is usable). Charging is possible with a Wallbox up to 22 kW or with a fast charger up to 80 kW. The range is 235 km.
The motor has a power output of 140 kW (188 hp) and a maximum torque of 400 Nm. This gives the eDaily a top speed of 120 km/h. A trailer with a maximum weight of 3.5 tonnes can be coupled behind this vehicle.
Available with leaf springs or air suspension, at your choice. Also available with 7.2 tonnes GVW (with dual rear wheels). In the photo, this chassis is equipped with a swing-wall body (side panels folding upwards) from Fahrzeugbau Heinz Böse GmbH, configured for the transport of soft drink or beer crates.
technical specifications *) Iveco eDaily 38S14E/P Chassis model year 2025 - engine type electric emission class Z max. power 140 kW max. torque 400 Nm drive rear axle number of tires 4 axle configuration 4x2 wheelbase 345 cm gross vehicle weight 3800 kg max. front axle load approx. 2500 kg max. rear axle load approx. 5350 kg range 235 km drive battery capacity 148 kWh max. charging power 80 kW max. trailer weight 3500 kg max. body width 235 cm chassis height approx. 68 cm number of seats 3 top speed 120 km/h *) subject to change. Exact specifications can be obtained from the supplier.
